| As shown in figures "B" and "C" of the illustration, what should be the switch position and which test lead terminal jacks should be used if your intent is to measure AC frequency?. |
| A) switch position "6" and terminal jacks "3 and 4" |
| B) switch position "7" and terminal jacks "3 and 4" |
| C) switch position "1" and terminal jacks "1 and 4" |
| D) switch position "1" and terminal jacks "3 and 4" |
loading answer...
The U.S. Coast Guard has not yet released this Illustration.
