| The illustration shown is called an exploded drawing and is intended to show the __________ . |
| A) internal shape of all component parts |
| B) total number of parts in the assembled component |
| C) parts aligned in the correct order of reassembly |
| D) disassembled component in a one point perspective view |
loading answer...
Illustration GS-0025
