| As shown in figures "E" and "F" of the pictured high voltage rack mounted circuit breaker, which figure represents the circuit breaker position when in the open or tripped position? Illustration EL-0167 |
| A) A |
| B) B |
| C) C |
| D) D |
loading answer...
Illustration EL-0167
| Comments |
|---|
| Glennsfuller - 2023-12-05 05:42:57 Member (5) |
| question has nothing to do with the illustration |
| andrewmillar - 2017-10-14 15:05:26 Member (4) |
| those breakers are completely racked out of the cubicle answer should be D |
| firesalmon - 2014-12-29 08:25:20 Registered (13) |
| Image will not load (EL-0167) |
