Engine : Electricity - 1176/1386
|
|---|
| « Previous Question |
| As shown in figure "A" of the illustration, with a digital multimeter set up as an ohmmeter, what set of readings would be consistent with an open in phase "C" of the single circuit, wye- connected stator windings as shown? EL-0201 |
| A) T1 to T2: "OL ohms"; T2 to T3: "1.8 ohms"; T3 to T1: "1.8 ohms" |
| B) T1 to T2: "OL ohms"; T2 to T3: "OL ohms"; T3 to T1: "1.8 ohms" |
| C) T1 to T2: "1.8 ohms"; T2 to T3: "OL ohms"; T3 to T1: "OL ohms" |
| D) T1 to T2: "OL ohms"; T2 to T3: "1.8 ohms"; T3 to T1: "OL ohms" |
loading answer...
Illustration EL-0201
| Comments |
|---|
| sboston - 2016-12-19 21:05:57 Member (10) |
| I think the intent was to say "open in phase B as shown in the diagram". |
